io Amplifier

 The io has been designed to offer exceptional Rega performance at an affordable price point. It uses the same amplifier stage as the multi-award winning Brio now designed to run at 30 W per channel into 8 Ω. The io features two line level inputs, a high specification Rega moving magnet phono stage, and a dedicated high quality headphone output. The io will integrate seamlessly into any home audio system whilst remaining simple to use and easy to set up. A must for demonstration.

Because music matters
The io uses the same power amplifier and phono stage as its larger brother, the multi-award winning Brio. The io aims to deliver exceptional sound quality in a smaller and more cost effective package. The class A/B circuit shares its DNA with the rest of Rega’s amplifiers, and as usual, great care has been taken in component selection. Sanken output transistors and an Alps volume potentiometer and a linear power supply that enables an output of 30 watts per channel into 8 Ω. Two line level inputs and a high quality moving magnet phono input are available as sources. There is a headphone output provided on the front of the unit for powering standard hi-fi headphones; this is driven from the power amplifier stage of the unit through relays to avoid signal degradation when headphones are inserted or the product is muted. A new redesigned mini remote

• Integrated phono stage
• Headphone socket
• Mini remote control
• All new custom designed chassis
• Lifetime warranty against manufacture defects

Amplifier Output

• Power Outputs (at rated 230/115V supply voltage):  30W per channel into 8Ω
• Note:  Continued high level use into loads of 6Ω or less may cause the case to exceed 40°C above ambient temperature and activate the thermal shut down.

Headphone Output

• No Load = 8V
• 32Ω = 1.6V
• 54Ω = 2.4V
• 300Ω = 5.7V
• Source Impedance = 109Ω

Frequency Response

• Phono Input:  15Hz to 40kHz (-3dB) / 27Hz to 20.5kHz (-1dB)
• Line Input:  12Hz (-1dB) to 43kHz (-3dB)
• RIAA Accuracy:  100Hz to 10kHz ±0.4dB typically better than ±0.3dB

Sensitivity

• Phono Input:  2.1mV @ 47kΩ in parallel with 220pF
• Line Inputs 2-3:  210mV @ 47kΩ

Dimensions/Weight

• Dimensions (WxHxD):  180 x 68 x 290mm (7.1 x 2.7 x 11.4in)
• Weight:  2.9kg (6.4lbs)

Power

• Power Supply:  AC supply 230V / 220V / 115V / 100V nominal ±10%
• Power Consumption: 135W @ 230V / 220V / 115V / 100V into the rated load of 8Ω
• Fuse Ratings:
  • T1.6AL 250V: 230V / 50Hz and 220V / 60Hz
  • T3.15AL 250V: 115V / 60Hz and 100V / 50/60 Hz
• Remote Batteries:  AAA (1.5V) x 2
